Introduction

Welcome to the Document Intelligence API, a comprehensive solution engineered to revolutionize your data processing and verification needs. This advanced tool utilizes cutting-edge machine learning and image analysis technologies, enabling efficient extraction of data from various identity documents, sophisticated ID classification, detailed image quality analysis, and precise face extraction where applicable.

The primary aim of this API is to enhance the operational workflow within your organization. By automating complex tasks such as data extraction, document verification, and compliance assurance, the Document Intelligence API allows for a substantial reduction in manual effort, heightened accuracy, and robust security.

Importantly, the broad versatility of this API makes it an invaluable asset across various industries, from banking, healthcare, and insurance to real estate and government services. By integrating our API, these sectors can witness a significant improvement in operational efficiency, risk management, and decision-making processes.

API Details

Endpoint

POST https://signzy.tech/api/v2/patrons/<patron-id>/documentIntelligence

POST https://preproduction.signzy.tech/api/v2/patrons/<patron-id>/documentIntelligence

Request body parameters

Parameter	Data Type	Description	Required
task	String	Defines the task we want to perform on this API. The value should be "idIntelligence".	Yes
essentials	Object	Wrapper containing all the information required for processing to be done on identity documents.	yes
essentials.frontUrl	String	The URL of the front image of the ID card. In case you have a multipage PDF document of your ID card then you can use frontURL to pass data to the API.	No
essentials.backUrl	String	The URL of the back image of the ID card.	No
essentials.country	String	The country where the ID card was issued. Check the complete list of supported countries here.	Yes
essentials.idType	String	The type of ID card (e.g. Driving license, VISA, Passport, etc.). Check the complete list of supported documents here.	Yes
essentials.performImageQualityAnalysis	Boolean	Indicates whether image quality analysis should be performed (default is true).	No
essentials.performIdClassification	Boolean	Indicates whether ID card classification should be performed (default is true).	No
essentials.performIdExtraction	Boolean	Indicates whether ID card data extraction should be performed (default is true).	No
essentials.performFaceExtraction	Boolean	Indicates whether face extraction should be performed (default is true).	No
essentials.imageQualityThreshold	Float	The preferred threshold for the image quality score (Between 0.05 and 0.95, the default is 0.5).	No

Note: Either one of frontUrl or backURL needs to be passed while making the API call.

{
    "task": "idIntelligence",
    "essentials": {
        "frontUrl": "https://domain/....hotesd_image..../image.jpg",
        "backUrl": "",
        "country": "United States",
        "idType": "Passport",
        "performImageQualityAnalysis": true,
        "performIdClassification": true,
        "performIdExtraction": true,
        "performFaceExtraction": true,
        "imageQualityThreshold": 0.5
    }
}

Request headers

Name	Value	Required	Description
Content-Type	application/json	Yes	The type of content that the request body contains.
Authorization	XXXXXXXXXXX	Yes	An authentication token to authorize the request. Reach out to the Signzy support team to get one created.

Code Samples

package main

import (
  "fmt"
  "strings"
  "net/http"
  "io/ioutil"
)

func main() {

  url := "https://preproduction.signzy.tech/api/v2/patrons/<patron-id>/documentIntelligence"
  method := "POST"

  payload := strings.NewReader(`{
    "task": "idIntelligence",
    "essentials": {
        "frontUrl": "https://domain/....hotesd_image..../image.jpg",
        "backUrl": "",
        "country": "United States",
        "idType": "Passport",
        "performImageQualityAnalysis": true,
        "performIdClassification": true,
        "performIdExtraction": true,
        "performFaceExtraction": true,
        "imageQualityThreshold": 0.5
    }
}`)

  client := &http.Client {
  }
  req, err := http.NewRequest(method, url, payload)

  if err != nil {
    fmt.Println(err)
    return
  }
  req.Header.Add("authorization", "{{access_token}}")
  req.Header.Add("Content-Type", "application/json")

  res, err := client.Do(req)
  if err != nil {
    fmt.Println(err)
    return
  }
  defer res.Body.Close()

  body, err := ioutil.ReadAll(res.Body)
  if err != nil {
    fmt.Println(err)
    return
  }
  fmt.Println(string(body))
}

Response body parameters

Parameter	Data type	Description
essentials	Object	Same as the essentials object passed in the request body.
result	Object	Contains the results after processing the ID document.
result.results	Object
result.results.predictedIddTypeFront	String	Id classification of the front side of the ID card. In case you have passed a multipage PDF document(containing back and front in single file) of your ID card in the request then you will get the predicted ID type of document as part of this field. Note: For multipage PDFs ID classification/prediction might not work properly.
result.results.predictedIddTypeBack	String	Id classification of the back side of the ID card.
result.results.idExpired	String	Defines if the ID card is expired or not. "False" means the id card is not expired and "True" means it's expired.
result.results.extractedFields	Object	Data extraction results from the ID document.
result.results.extractedFields.firstName	String	The 'firstName' parameter represents the extracted first name of the individual as it appears on their identity document.
result.results.extractedFields.lastName	String	The 'lastName' parameter represents the extracted last name of the individual as it appears on their identity document.
result.results.extractedFields.names	String
result.results.extractedFields.address	String	The 'address' parameter denotes the extracted residential address of the individual as it appears on their identity document.
result.results.extractedFields.number	String	The 'number' parameter represents the extracted unique identification number from the individual's identity document, such as a passport number, driver's license number, etc.
result.results.extractedFields.DOB	String	The 'DOB' (Date of Birth) parameter refers to the individual's birth date extracted from the identity document. It is typically returned in the format of DD/MM/YYYY.
result.results.extractedFields.issuingState	String	The 'issuingState' parameter signifies the state or the administrative division that issued the individual's identity document.
result.results.extractedFields.expiryDate	String	The 'expiryDate' parameter refers to the date of expiration of the identity document, usually returned in the format of DD/MM/YYYY.
result.results.extractedFields.nationality	String	The 'nationality' parameter refers to the country that issued the individual's identity document.
result.results.extractedFields.gender	String	The 'gender' parameter denotes the gender of the individual as listed on their identity document.
result.results.extractedFields.additionalData	Object	The 'additionalData' parameter includes any other information extracted from the identity document that does not fit into the previously defined extractedFields parameters. This could include various attributes depending on the specific identity document, such as profession, employer, etc.
result.results.imageQualityFront	Object	This parameter contains the assessment results of the image quality for the front side of the document. Note: In case you are passing a multipage PDF in input then you won't get image quality analysis results as part of response.
result.results.imageQualityFront.qualityScores	Object	This object contains the quality scores for several criteria including text quality, brightness, sharpness, and compression quality. Each criterion has two sub-fields: "valid" and "score". "valid" indicates whether the criterion is met ("yes") or not ("no"), and "score" is a numerical value representing the quality score for that criterion.
result.results.imageQualityFront.qualityScores.textQuality	Object	This object contains the quality score of the text in the image. It includes two sub-fields: "valid" and "score".
result.results.imageQualityFront.qualityScores.valid	String	The 'valid' field indicates whether the image quality threshold is above than the one defined in the request. A value of "yes" implies that the criterion is fulfilled, and "no" implies it is not.
result.results.imageQualityFront.qualityScores.score	String	The 'score' field is a numerical value representing the quality score for that specific criterion. The score typically ranges between "0" (lowest quality) and "1.0" (highest quality).
result.results.imageQualityFront.qualityScores.brightness	Object	This object contains the quality score related to the brightness of the image. It includes two sub-fields: "valid" and "score".
result.results.imageQualityFront.qualityScores.sharpness	Object	This object contains the quality score related to the sharpness of the image. It includes two sub-fields: "valid" and "score".
result.results.imageQualityFront.qualityScores.compressionQuality	Object	This object contains the quality score related to the compression quality of the image. It includes two sub-fields: "valid" and "score".
result.results.imageQualityFront.score	String	This field represents the minimum of all the quality scores of the image.
result.results.imageQualityFront.imageQuality	String	This field provides an overall qualitative assessment of the image quality, such as "high", "medium", or "low".
result.results.imageQualityBack	Object	This parameter contains the assessment results of the image quality for the back side of the document. The nested properties are same as ones defined above for "imageQualityFront" Note: In case you are passing a multipage PDF in input then you won't get image quality analysis results as part of response.
result.results.faceUrl	String	The 'faceURL' parameter represents the URL of the extracted face image from the individual's identity document.

Note: In case you pass a multipage PDF as input in frontUrl, the ID classification might not work expected in some cases. Also the image quality analysis won't be done for multi page PDFs.

{
    "essentials": {
        "frontUrl": "",
        "backUrl": "",
        "country": "",
        "idType": "",
        "performImageQualityAnalysis": true/false,
        "performIdClassification": true/false,
        "performIdExtraction": true/false,
        "performFaceExtraction": true/false,
        "imageQualityThreshold": 0.5 (optional)
    },
    "id": "<Signzy generated ID>",
    "patronId": "<patron id>",
    "task": "idIntelligence",
    "result": {
        "faceUrl": "...url of cropped face from the Id document...",
        "imageQualityFront": {
            "qualityScores": {
                "textQuality": {
                    "valid": "yes/no",
                    "score": "...validity score..."
                },
                "sharpness": {
                    "valid": "yes/no",
                    "score": "...validity score..."
                },
                "brightness": {
                    "valid": "yes/no",
                    "score": "...validity score..."
                },
                "compressionQuality": {
                    "valid": "yes/no",
                    "score": "...validity score..."
                }
            },
            "score": "...total score...",
            "summary": "...summary...",
            "msg": "...msg...",
            "status": "...status...",
            "imageQuality": "...image quality..."
        },
        "imageQualityBack": {
            "qualityScores": {
                "textQuality": {
                    "valid": "yes/no",
                    "score": "...validity score..."
                },
                "sharpness": {
                    "valid": "yes/no",
                    "score": "...validity score..."
                },
                "brightness": {
                    "valid": "yes/no",
                    "score": "...validity score..."
                },
                "compressionQuality": {
                    "valid": "yes/no",
                    "score": "...validity score..."
                }
            },
            "score": "...total score...",
            "summary": "...summary...",
            "msg": "...msg...",
            "status": "...status...",
            "imageQuality": "...image quality..."
        },
        "predictedIdTypeFront": "...predicted id type...",
        "predictedIdTypeBack": "...predicted id type...",
        "idExpired": "True/False",
        "extractedFields": {
            "firstName": "",
            "lastName": "",
            "names": "",
            "address": "",
            "number": "",
            "DOB": "",
            "issuingState": "",
            "expiryDate": "",
            "nationality": "",
            "gender": "",
            "additionalData": {
                // Will vary depending upon data that can be extracted from ID cards
            }
        }
    }
}

Image quality requirements

Good lighting

Good lighting helps to achieve better OCR results. If the image is too dark or too bright, the document might not be processed successfully.

Avoid reflections

Glares and reflections interfere with processing and reduce data extraction accuracy. We recommend not to use the flash of your mobile device when capturing document images.

Focus and sharpness

Make sure the image is clear and there are no blurred areas.

Angle

The tilt angle of the document should not exceed 10 degrees in any direction (horizontal or vertical).

Margins (too small)

Make sure there is minimal space around the document. It is recommended that the document takes up 70-80% of the image.

Margins (too big)

Make sure the space around the document does not take up more than 20-30% of the image. It is recommended that the document takes up 70-80% of the image.

Contrast

The document should be in clear contrast to the background. A light-colored document on a light background, as well as a dark-colored document on a dark background, might not be recognized.

Resolution of the image

To achieve a good quality of recognition of identification documents, we recommend that you provide images captured by a camera with a resolution of at least Full HD (1920×1080) and autofocus.

Extraneous objects

Make sure your hands or other objects do not cover document data.
